Proline Prosonic Flow W 400 HART
Endress+Hauser
 53 Using the example of the local display
To call up the measures to rectify a diagnostic event:
• Via local display →  134
• Via web browser →  135
• Via "FieldCare" operating tool →  137
• Via "DeviceCare" operating tool →  137

12.10 Event logbook

12.10.1 Reading out the event logbook

A chronological overview of the event messages that have occurred is provided in the
Events list submenu.
Navigation path
Diagnostics menu → Event logbook submenu → Events list
 54 Using the example of the local display
• A maximum of 20 event messages can be displayed in chronological order.
• If the Extended HistoROM application package (order option) is enabled in the device,
the event list can contain up to 100 entries.
The event history includes entries for:
• Diagnostic events →  138
• Information events →  144
In addition to the operating time when the event occurred, each event is also assigned a
symbol that indicates whether the event has occurred or is finished:
• Diagnostics event
• : Occurrence of the event
• : End of the event
• Information event
: Occurrence of the event
To call up the measures to rectify a diagnostic event:
• Via local display →  134
• Via web browser →  135
• Via "FieldCare" operating tool →  137
• Via "DeviceCare" operating tool →  137
For filtering the displayed event messages →  144
/ ../Diagnose list
Diagnostics
F273 Main electronic
Diagnostics 2
Diagnostics 3
/ ../Eventlist
I1091 Config. change
I1157 Mem.err. ev.list
0d01h19m10s
F311 Electr. failure
Diagnosis and troubleshooting
F
A0014006-EN
A0014008-EN
143
