Operation options
76
3. Enter the password:
Serial number of the measuring device ex-works (e.g. L100A802000).
 The LED on the display module flashes. It is now possible to operate the
measuring device with the web browser, FieldCare or DeviceCare.
The serial number can be found on the nameplate.
To ensure the safe and swift assignment of the WLAN network to the measuring
point, it is advisable to change the SSID name. It should be possible to clearly assign
the new SSID name to the measuring point (e.g. tag name) because it is displayed as
the WLAN network.
Terminating the WLAN connection
‣
After configuring the device:
Terminate the WLAN connection between the mobile terminal and measuring device.
8.5.2

FieldCare

Function range
FDT-based (Field Device Technology) plant asset management tool from Endress+Hauser.
It can configure all smart field units in a system and helps you manage them. By using the
status information, it is also a simple but effective way of checking their status and
condition.
Access is via:
• HART protocol
• CDI-RJ45 service interface
Typical functions:
• Transmitter parameter configuration
• Loading and saving of device data (upload/download)
• Documentation of the measuring point
• Visualization of the measured value memory (line recorder) and event logbook
• Operating Instructions BA00027S
• Operating Instructions BA00059S
Source for device description files →  79
Establishing a connection
1. Start FieldCare and launch the project.
2. In the network: Add a device.
 The Add device window opens.
3. Select the CDI Communication TCP/IP option from the list and press OK to confirm.
4. Right-click CDI Communication TCP/IP and select the Add device option in the
context menu that opens.
5. Select the desired device from the list and press OK to confirm.
 The CDI Communication TCP/IP (Configuration) window opens.
6. Enter the device address in the IP address field: 192.168.1.212 and press Enter to
confirm.
7. Establish the online connection to the device.
• Operating Instructions BA00027S
• Operating Instructions BA00059S
