Technical data
Mounting requirements
Ambient temperature
range
Storage temperature
Relative humidity
Operating height
Degree of protection
Shock and vibration
resistance
162
16.7

Mounting

→  19
16.8

Environment

→  27
The storage temperature for all components (except display modules and order code for
"Sensor version", options AG, AH) corresponds to the ambient temperature range→  27.
Display modules
–40 to +60 °C (–40 to +140 °F)
The device is suitable for use outdoors and indoors with a relative humidity of 5 to 95 %.
According to EN 61010-1
• ≤ 2 000 m (6 562 ft)
• > 2 000 m (6 562 ft) with additional overvoltage protection (e.g. Endress+Hauser HAW
Series)
Transmitter
• IP66/67, type 4X enclosure, suitable for pollution degree 4
• When the housing is open: IP20, type 1 enclosure, suitable for pollution degree 2
• Display module: IP20, type 1 enclosure, suitable for pollution degree 2
Sensor
• Standard: IP66/67, type 4X enclosure, suitable for pollution degree 4
• Optionally available: IP68, type 6P enclosure, suitable for pollution degree 4
External WLAN antenna
IP67
Vibration sinusoidal, in accordance with IEC 60068-2-6
• 2 to 8.4 Hz, 7.5 mm peak
• 8.4 to 2 000 Hz, 2 g peak for transmitter, 1 g peak for sensor
Vibration broad-band random, according to IEC 60068-2-64
• 10 to 200 Hz, 0.01 g 2 /Hz
• 200 to 2 000 Hz, 0.003 g
• Total: 2.70 g rms
Shock half-sine, according to IEC 60068-2-27
6 ms 50 g
Rough handling shocks according to IEC 60068-2-31
2 /Hz
