Proline Prosonic Flow W 400 HART
Parameter
Pipe circumference
Pipe outer diameter
Pipe wall thickness
Liner material
Liner sound velocity
Liner thickness
Sensor type
Sensor coupling
Mounting type
Cable length
Endress+Hauser
Prerequisite
The Pipe circumference
option is selected in the Pipe
dimensions parameter.
The Diameter option is
selected in Pipe dimensions
parameter.
–
–
The Unknown liner material
option is selected in the Liner
material parameter.
One of the following options is
selected in the Liner material
parameter:
• Cement
• Rubber
• Epoxy resin
• Unknown liner material
–
The following option is
selected in Sensor type
parameter:
• C-030-A
• C-050-A
• C-100-A
• C-100-B
• C-100-C
• C-200-A
• C-200-B
• C-200-C
• C-500-A
–
–
Description
Define the pipe circumference.
Define the outer diameter of
the pipe.
Enter the pipe wall thickness.
Select liner material.
Define the sound velocity of
liner material.
Define the thickness of liner.
Select sensor type.
Select coupling medium.
Select the number of traverses
(number of times the signal
passes through the medium).
• (1) direct option: Sensor
arrangement with 1 traverse
• (2) V-mounting option:
Sensor arrangement with 2
traverses
• (3) Z-Mounting option:
Sensor arrangement with 3
traverses
• (4) W-mounting option:
Sensor arrangement with 4
traverses
Enter length of sensor cables.
Commissioning
Selection / User Factory setting
entry / User
interface
30 to 62 800 mm –
0 to 20 000 mm –
Positive floating 3 mm
point number
• None –
• Cement
• Rubber
• Epoxy resin
• Unknown liner
material
800.0 to 3 800.0 m/s –
0 to 100 mm –
• C-030-A As per order
• C-050-A
• C-100-A
• C-100-B
• C-100-C
• C-200-A
• C-200-B
• C-200-C
• C-500-A
• Coupling pad –
• Coupling paste
• 1 traverse Automatic
• 2 traverses
• 3 traverses
• 4 traverses
• Automatic
0 to 200 000 mm As per order
