Connect Tech COM Express Type 2 Carrier Board - User Manual

System Block Diagram

COM Express Module
CPU
and
Chipset
8
COM Express
A/B Connector
PCI Express lanes x 4
SATA x 3
GBE
USB x 4
LVDS Video
HD Audio
VGA
Power Control
LPC Bus
COM Express
C/D Connector
SDVO x 1 (B)
IDE
PCI (32bit)
Connect Tech COM Express Carrier
LVDS panel and
back light power
HD Audio codec
2 x 3.5mm audio jacks
CS4207
SCH3114 Super I/O
CS7307 DVI transmitter
Compact Flash Type I
socket
Revision 0.03
PC/104 Express
slots x 4
SATA 1 connector
mSATA 2 connector
SATA 3 connector
GBE Magnetics and
RJ connector
Standard USB jacks
LVDS Video and
Power connectors
VGA filtering and
2x10 pin connector
Power Supply
and control
2 x RS232 and
2 x RS485 Serial
HDMI Connector
PCI-104 slots x 4
