A
PPENDIX
P
ROTECTOR
D
IMENSIONS
Radioisotope Model Widths
4' 5'
A 48.00 60.00
B 38.25 50.25
Dimensions in inches. CAD layouts available upon request.
Product Service 1-800-522-7658
B
R
ADIOISOTOPE
6' 8'
72.00 96.00
62.25 86.25
Figure B-1
45
