Creating Fixed Displays
Modifying Squares
Procedure 1. Select "SQUARE" from the fixed display menu, then press the [F2] (Modify)
key.
A j mark will be displayed at the top left corner of the square.
It is also possible to proceed straight to step 3. by left clicking on the square to
be modified (see p.57).
2. Locate the cursor at the j mark of the square to be modified and press the
key.
3. Select the required item and execute the modification.
S Attribute: Select to change the display attribute.
S Color: If using an NT30C or NT610C, select to change the line
color.
S Display position: Select to move the bottom right point of the square.
Pressing the [Esc] key makes it also possible to move the
top left point of the square.
Change the size and shape and then press the
4. Press the [Esc] key to quit modification.
Section 4-3
key.
