8.1 Technical Specifications
8.1.1. Classifications:
Applied Parts:
Mode of operation:
Electric shock protection:
Ingress of liquid protection:
Flammable anaesthetic mixtures: Not protected/Not suitable for use
Oxygen rich environments:
®
The Magstim Rapid
(Conducted and radiated emissions comply with CISPR 11 Group 2 Class A limits
and immune to the Professional Healthcare Environment). See "2.3 Warnings" on
page 25 for more information.
8.1.2. Output
Stimulator:
Stimulation pulse waveform:
Stimulation power range:
Coils:
Coil
The D70 MT remote coil
AirFilm ® Coil
* Peak Magnetic Flux Density [Tesla] at surface @ 100% displayed output
8.1.3. External Interfaces:
Any interface cable which connects The stimulator to an external piece of
equipment must be no more than 1.5m in length.
Memory Card:
Trigger Out:
Socket Type:
Open Collector:
Isolation:
Signal:
The Magstim ® Company Ltd.
Type BF
Continuous
Class 1
IPx0
Not protected/Not suitable for use
2
Therapy System complies with IEC 60601-1-2:2014, Edition 4.0
Biphasic single cosine, Period 300 -400μs
0% -100% (Max discharge voltage)
Resolution 1%, Accuracy 2%
Typical Inductance
FAT 16, formatted, SD memory card, max 512mb.
Active low
BNC (centre pin active, shell reference)
Max pull up Voltage +12V, Max sink current 10mA
±30V to Protective Earth
100μs low pulse on system trigger
15.5 μH
12 μH
MOP16-EN-02
Peak magnetic field*
1 T
1 T
