1.9 Magstim
The highly mobile Cart securely and neatly houses the stimulator creating an all-
in-one solution.
Cart Mounted
Coil Arm
Coil Arm Clamp
Lockable Wheels
Figure 1.9: Cart
Cart Mounted Coil Arm
A secure,
manoeuvrable coil arm which is
mounted on the cart using one of
the coil arm clamps.
See "1.10 Cart Mounted Coil Arm" on
page 17 for more information.
Coil Arm Clamps
A clamp is provided on either side
of the cart to allow the coil arm to
be mounted on the left or right
depending on user preference.
The Magstim ® Company Ltd.
®
Stimulator Cart
versatile
Lockable Wheels
and The
increased manoeuvrability, whilst
the individual
stability. The brakes must be locked
when the equipment is not being
moved.
Stimulator Shelf
The stimulator should be placed on
the top shelf of the cart as shown.
Storage Shelves
Two lower shelves are provided for
extra storage of accessories.
Coil Arm Clamp
Stimulator Shelf
Storage
Shelves
rotating wheels
brakes
