Wait Time (s)
This allows the user to set the time between each 'train' of pulses to a value
between 1 and 540s (seconds), in 0.1s steps.
If the wait time is below the minimum required for the set protocol, the UI
will display 'Wait period too short, auto-set to minimum'. Select 'YES' to set
the minimum required wait time for the set protocol. Select 'NO' to reset the
protocol parameters manually.
Number of Trains
Set the amount of pulse 'trains' to be delivered during the treatment session
between 1 and 999, in steps of 1.
Total Number of Pulses
The total number of pulses calculated to be delivered by the set protocol.
None of the settings above can cause the 'Total Number of Pulses' to exceed
60000.
Pictorial Representation
A pictorial representation of the set protocol is displayed on the screen:
Frequency
Wait Time
Power
Duration
Figure 5.7: Repetitive standard mode illustration
Charge Delay
Toggle the charge delay on and off (see "ii. Charge Delay" on page 61).
Duration (charge delay)
Set the charge delay duration between 1ms and 10000ms in 1ms increments.
The 'Wait Time' will automatically be adjusted if required.
Information Window
The white information window should display 'Coil OK to run,' but if necessary will
alert the user to actions required or protocols that are unable to be completed
see "6.1 Warning Messages" on page 82.
Print
An optional printer is available. Contact us for more information.
