iii. Rapid2 Plus
HV Socket (Plus
The Plus 1 connection for the HV cable
to connect to the PSU (see page 36).
Warning: High voltages can be
present on this connector.
HV Socket (Mainframe-Plus
The Plus 1 connection for the HV cable
to connect to the mainframe (see
page 36).
Warning: High voltages can be
present on this connector.
1
Plus Power Switch
The power switch for the Plus
allows the unit to be switched on (I)
or off (O).
Power Link Socket (Plus
The PSU connection for the link lead
to connect to the mainframe (see
page 36).
vi. Rapid2 Power Supply Unit (PSU)
HV Socket (PSU)
The PSU connection for the HV cable
to connect to the mainframe (see
page 36).
Warning: High voltages can be
present on this connector.
Power Link Socket (PSU)
The PSU connection for the link lead
to connect to the mainframe (see
page 36).
Power Supply Socket
The socket for the power cable
provided, to connect the PSU to the
mains supply (see page 36).
The Magstim ® Company Ltd.
1 Unit
(Super Rapid
1
-PSU)
1 )
1
Unit
1
-PSU)
2 Plus 1 Only)
HV Sockets (Plus
The Plus 1 unit requires a further HV
cable to connect the internal Plus
PSU (see page 36).
Warning: High voltages can be
present on these connectors.
Earth Strap Connector (Plus
The Plus 1 connection for the earth
straps.
The stimulator must not be used
without the earth straps fitted (see
page 36).
Power Link Socket (Mainframe-
Plus 1 )
The Plus 1 connection for the link lead
to connect to the mainframe (see
page 36).
Power Supply Socket
The Plus 1 connection for the additional
power cable provided (see page 36).
Each power cable should be plugged
into a separate mains outlet.
Power Supply Socket (2)
The dual PSU (Super Rapid
Rapid 2 Plus
supply socket (see page 36). Each
power cable should be plugged into
a separate mains outlet.
Earth Strap Connector (PSU)
The mainframe connection for the
earth strap.
The stimulator must not be used
without the earth straps fitted (see
page 36).
