MAGSTIM The Rapid2 Operating Manual page 14

On/Standby Switch
Coil Output Socket
Power Status Indicator (Plus¹ PSU)
Status / Fault Indicator (Plus¹ PSU)
Power Status Indicator (PSU)
Status / Fault Indicator (PSU)
Figure 1.3: Super Rapid2 Plus
ii. Rapid2 Mainframe
On/Standby Switch
This switch toggles the stimulator
between on and standby.
Coil Output Socket
This socket is used to connect the
stimulating coil to the stimulator.
The Magstim ® Company Ltd.
1
Stimulator front view
Power Indicator
Ready Indicator
Power Indicator
This indicator flashes
stimulator is
illuminates when the stimulator is on.
Ready Indicator
This indicator illuminates when the
stimulator is charged ready to be
triggered. If lit high voltages are
present within the system.
MOP16-EN-02
i. Rapid User Interface
2
ii. Rapid 2 Mainframe
Power Indicator (Plus¹)
Status / Fault Indicator (Plus¹)
iii. Rapid 2 Plus¹ Unit
iv. Rapid Power Supply Unit
2
when the
in standby and
8
