5.9 System Details

This screen shows the part numbers, software revision and serial number
information for the stimulator UI, Mainframe (Base), PSU and the coil currently
connected.
Back
Return to the system options
menu.
Print
An optional printer is available.
Contact us for more information.

5.10 File Maintenance

The file maintenance
allows the user to store and manage
protocols.
5.10.1. File Selection
• Select either the 'Local Store'
panel or the 'Memory Card' panel
(if available), and use the control
dial to scroll the listed files.
• > Shows the selected file.
5.10.2. Saving A Protocol
• From the 'Options Menu' select
'Repetitive Mode'
• Set the required protocol by
selecting each
using the control dial.
• Press 'Save Session'
• On the file maintenance screen
• Enter a unique name for your file, between 1 and 18 characters long.
• Press 'Save' (on the keyboard) to set the file name.
• Press 'Save as'
'YES' to store your protocol on this file.
The Magstim ® Company Ltd.
window
Figure 5.16: System details screen
.
window and
Figure 5.17: File maintenance window
.
(Figure
, a prompt will be ask if you wish to overwrite the file, select
5.17), select 'New'
MOP16-EN-02
.
75
