1.5 Product Overview

The Magstim ®
and delivers non-invasive, magnetic stimulation.
AirFilm Coil
®
Cart Mounted
Coil Arm
Figure 1.1: Magstim
AirFilm ® Coil (page 13)
The coil delivers the stimulation pulses to
the patient during a treatment session.
The AirFilm ® Coil benefits from a smart
internal cooling system to efficiently
manage the temperature of the coil.
Cart Mounted Coil Arm (page 17)
A holding arm with an articulated
locking arm, the Cart Mounted Coil Arm
provides effortless manipulation of the
Air Cooled Coil for precise fixation over
the treatment location.
D70 MT Coil (page 14)
This hand held coil is designed for the
determination of the Motor Threshold.
The Magstim ® Company Ltd.
Rapid 2 Therapy System is a TMS Therapy System which produces
®
Rapid2 Therapy System overview
D70 MT Coil
Rapid² Stimulator (page 7)
Configurations of the Rapid² stimulator
consist of 3 main components; the
Rapid² mainframe, a dual or single
Rapid² PSU (Power Supply Unit) and the
Rapid² UI (User Interface). The Rapid²
Plus1 has the additional of a Plus1 Unit.
Stimulator Cart (page 17)
Highly mobile, with locking swivel
wheels, the Cart securely and neatly
houses the stimulator and connects to
the Cart Mounted Coil Arm to provide
an all-in-one solution.
MOP16-EN-02
Rapid Stimulator
2
Stimulator Cart
6
