Changing the Timer/Counter PV Refresh Mode
320
TENTH-MS TIMER (CJ1-H-R CPU Units Only)
Instruction name
Mnemonic
S (timer set value)
Setting time (unit: 0.0001 s) 0 to 0.9999 s
HUNDREDTH-MS TIMER (CJ1-H-R CPU Units Only)
Instruction name
Mnemonic
S (timer set value)
Setting time (unit: 0.00001 s) 0 to 0.09999 s
ACCUMULATIVE TIMER (100 ms)
Instruction name
Mnemonic
S (timer set value)
Setting time (unit: 0.1 s)
LONG TIMER (100 ms)
Instruction name
Mnemonic
S, S+1 (timer set values)
Setting time (unit: 0.1 s)
MULTI-OUTPUT TIMER (100 ms)
Instruction name
Mnemonic
S to S-7 (each timer set
value)
Setting time (unit: 0.1 s)
COUNTER
Instruction name
Mnemonic
S (counter set value)
Setting
BCD mode
TIMU
#0000 to #9999 (BCD)
BCD mode
TMUH
#0000 to #9999 (BCD)
BCD mode
TTIM
#0000 to #9999 (BCD)
0 to 999.9 s
BCD mode
TIML
#00000000 to #99999999
(BCD)
0 to 999.9 s
BCD mode
MTIM
#0000 to #9999 (BCD)
0 to 999.9 s
BCD mode
CNT
#0000 to #9999 (BCD)
0 to 9,999 times
Section 6-4
Binary mode
TIMUX
&0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
0 to 6.5535 s
Binary mode
TMUHX
&0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
0 to 0.65535 s
Binary mode
TTIMX
&0 to &65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
0 to 6,553.5 s
Binary mode
TIMLX
&0 to &4294967295 (deci-
mal)
or #0000 to #FFFFFFFF
(hexadecimal)
0 to 6,553.5 s
Binary mode
MTIMX
&0 to &65535
or #0000 to #FFFF (hexa-
decimal)
0 to 6,553.5 s
Binary mode
CNTX
&0 to& 65535 (decimal)
or #0000 to #FFFF (hexa-
decimal)
0 to 65,535 times
