Manipulating Files
Procedure
1,2,3...
250
Unit/Board
CompoNet Units CS1W-CRM21
Customizable
Counter Units
Motion Control
Units
Position Control
Units
Position Control
Units
Loop Control
Board
Note Data from the Units and Boards listed above will be automatically backed up
for the simple backup operation. There is no setting available to include or
exclude them. If a Programming Console is used, however, operations are
supported individually for the user program area, parameter area, and I/O
memory areas. Refer to the Programming Console Operation Manual (W314)
for details.
The procedure for the simple backup operation is the same regardless of
whether or not data is being backed up from specific Units and Boards
(including writing, reading, and comparing).
■ Backing Up Data
1. Turn ON pin 7 on the CPU Unit's DIP switch.
2. Press and hold the Memory Card Power Supply Switch for three seconds.
Model numbers Data backed up for
simple backup when
used with CS1-H/CJ1-H
• Registration tables
CJ1W-CRM21
• Software settings
• Network parameters
• Slave parameters
CS1W-HIO01-V1 • User program
CS1W-HCP22-V1
• General-purpose read-
CS1W-HCA22-V1
only DM
CS1W-HCA12-V1
• Unit function setting area
• Information on expan-
sion instructions
• Ladder library
CS1W-MCH71 • Positioning data
CJ1W-MCH71
• System parameters
CS1W-MC221-V1
• G language programs
CS1W-MC421-V1
CJ1W-NCF71 • Common parameters
• Individual axis parame-
ters
CS1W- • Axis parameters
NC113/133/213/2
• Sequence data
33/413/433
• Speed data
Ver. 2.0 or later
• Acceleration/decelera-
CJ1W-
tion time data
NC113/133/213/2
• Dual timer data
33/413/433
• Zone data
Ver. 2.0 or later
CS1W-LCB01 • Function block data
CS1W-LCB05
• Block connection data
Section 5-2
Data capacity
used in Memory
Card for simple
CPU Unit backup
3.5 Kbytes
64 Kbytes
8,192 Kbytes
142 Kbytes
64 Kbytes
7 Kbytes
1,563 Kbytes
