PROGRAMS
Temporal Bone Ø100 mm
Temporal Bone Pair Ø100 mm
18 Planmeca ProMax 3D Max
The preprogrammed target areas for program type
Temporal Bone are (average jaw size):
Example:
Adult, Temporal Bone, Ø100 mm,
H90 mm, Left
The preprogrammed target area for program type
Temporal Bone Pair is (average jaw size):
Example:
Adult, Temporal Bone Pair, Ø100 mm, H90 mm
2/2
Program type Temporal Bone Pair takes two symmetrical
images: one from the left (1/2) and one from the right (2/2)
side of the patient. The imaging procedure is carried out in
two stages.
1/2
