PROGRAMS
Volume sizes for adults
Program type
SINUS
MIDDLE EAR
MIDDLE EAR PAIR
TEMPORAL BONE
TEMPORAL BONE PAIR
VERTEBRAE
AIRWAYS
Sinus Ø100 mm
Sinus Ø130 mm
16 Planmeca ProMax 3D Max
Ø50 mm
Ø50 x H55 mm
2 x Ø50 x H55 mm
The preprogrammed target areas for program type Sinus
are (average jaw size):
Example:
Adult, Sinus, Ø100 mm, H130 mm
Example:
Adult, Sinus, Ø130 mm, H130 mm
Ø100 mm
Ø100 x H90 mm
Ø100 x H130 mm
Ø100 x H90 mm
2 x Ø100 x H90 mm
Ø100 x H90 mm
Ø100 x H130 mm
Ø100 x H90 mm
Ø100 x H130 mm
Ø130 mm
Ø130 x H130 mm
Ø130 x H160 mm
Ø130 x H130 mm
Ø130 x H160 mm
