Middle Ear Ø50 mm
Middle Ear Pair Ø50 mm
User's Manual
The preprogrammed target areas for program type Middle
Ear are (average jaw size):
Example:
Adult, Middle Ear, Ø50 mm, H55 mm, Left
The preprogrammed target area for program type Middle
Ear Pair is (average jaw size):
Example:
Adult, Middle Ear Pair, Ø50 mm, H55 mm
2/2
Program type Middle Ear Pair takes two symmetrical
images: one from the left (1/2) and one from the right (2/2)
side of the patient. The imaging procedure is carried out in
two stages.
Planmeca ProMax 3D Max 17
PROGRAMS
1/2
