MAIN PARTS
5.4

Patient supports

5.5

Emergency stop button

Emergency stop button
8 Planmeca ProMax 3D Max
Support bars
Head band 25
(Part number 10028108)
Chin cup
The emergency stop button is located on the top of the
stationary column. Press the button to stop the X-ray unit
operating in an emergency. When the emergency stop
button is pressed down, all movements of the X-ray unit
are blocked and the unit will not generate radiation. The
up / down movement will stop within a distance of 10 mm
(0.4 in.).
A help message will appear on the control panel display.
Guide the patient away from the X-ray unit. Then release
the emergency stop button. The X-ray unit will
automatically restart.
