eBOX671B Series user's Manual
67
CNVI_WT_DATA0_D+
69
GND
71
CNVI_WT_CLK_D-
73
CNVI_WT_CLK_D+
75
GND
3.3.18 M.2 2230 Key M slot (SCN1)
The system comes with one M.2 Key E socket (PCIe & USB2.0)
3.3.19 HD Audio Digital Header (CN32, CN33)
This audio jack support for Audio Mic-In and Line-out.
Pin
Signal
1
Line Out
2
Microphone In
48
68
NC
70
NC
72
+3.3V_SBY
74
+3.3V_SBY
Jumper & Connector Settings
