  • Page 1 Series Embedded System User’s Manual...

  • Page 2: Disclaimers

    Axiomtek does not make any commitment to update any information in this manual. Axiomtek reserves the right to change or revise this document and/or product at any time without notice. No part of this document may be reproduced, stored in a retrieval system, or transmitted in any forms or by any means, electronic, mechanical, photocopying, recording, among others, without prior written permissions of Axiomtek Co., Ltd.

  • Page 3: Safety Precautions

    Safety Precautions Before getting started, please read the following important safety precautions. The eBOX630A does not come with an operating system which must be loaded first before installation of any software into the computer. Be sure to ground yourself to prevent static charge when installing any internal components.

  • Page 4: Classifications

    Classifications Degree of production against electric shock: not classified Degree of protection against ingress of water: IP40 Equipment not suitable for use in the presence of a flammable anesthetic mixture with air, oxygen or nitrous oxide. Mode of operation: Continuous...

  • Page 5: General Cleaning Tips

    General Cleaning Tips Please keep the following precautions in mind while understanding the details fully before and during any cleaning of the computer and any components within. A piece of dry cloth is ideal to clean the device. Be cautious of any tiny removable components when using a vacuum cleaner to absorb dirt on the floor.

  • Page 6: Scrap Computer Recycling

    Scrap Computer Recycling Please inform the nearest Axiomtek distributor as soon as possible for suitable solutions in case computers require maintenance or repair; or for recycling in case computers are out of order. Trademarks Acknowledgments Axiomtek is a trademark of Axiomtek Co., Ltd.

  • Page 7: Table Of Contents

    Table of Contents Disclaimers ......................ii Safety Precautions ....................iii Classifications ....................... iv General Cleaning Tips ................... v Scrap Computer Recycling ................... vi SECTION 1 INTRODUCTION................. 1 General Descriptions ................. 1 System Specifications ............... 2 1.2.1 CPU ........................2 1.2.2 I/O System ......................
  • Page 8 3.3.15 RS-232 Serial Port Connector (CN16, CN12) ..........31 3.3.16 SATA Connector (SATA 1 & 2) ..............32 3.3.17 SATA Power Connector (CN13,CN14) ............32 3.3.18 SIM Slot (CN9, CN5) ..................32 3.3.19 Full-Size PCI Express Mini Card Slot (CN8) ..........33 3.3.20 M.2 2280 Key M (CN6) ..................

  • Page 9: Section 1 Introduction

    Model List 1.1 General Descriptions ® ® The eBOX630A Series features 11th gen Intel Core™ i7/i5/i3 or Celeron Quad-core ULT processor (Tiger Lake UP3), high performance yet low power consumption, fan-less slim type design, -40°C to +60°C extended operating temperature, and 9V to 48V wide range DC power input with industrial-grade reliability.

  • Page 10: System Specifications

    Series User’s Manual Reliable and Stable Design ® ® The embedded system supports 11th gen Intel Core™ i7/i5/i3 or Celeron Quad-core ULT processor, along with the features of high performance, industrial-grade operation temperature/power input and multi-functional design that make it the best solution factory automation, machine vision, Edge Computing, Robotics applications.
  • Page 11 Series User’s Manual ⚫ Ethernet ◼ 2 x 10/100/1000/2500 Ethernet ports (i226-IT) ◼ 1 x 10/100/1000/2500 Ethernet ports (i226-LM supports AMT) ⚫ USB Ports ◼ 4 x USB 3.2 Gen 1 ◼ 2 x USB 2.0 ⚫ Serial Ports ◼...

  • Page 12: System Specifications

    Series User’s Manual ⚫ TPM 2.0 ◼ 1 x ST33HTPH2X32AHD8 1.2.3 System Specifications ⚫ Watchdog Timer ◼ 1-255 seconds or minutes; up to 255 levels. ⚫ Power Supply ◼ 9V-48V DC input ⚫ Operation Temperature ◼ -40°C to +60°C (-40°F to +140°F) with 0.5 m/s air flow at 9-48V DC Mode (with W.T.

  • Page 13: Driver Cd Contents

    Series User’s Manual 1.2.4 Driver CD Contents Please download the following eBOX630A drivers from the Axiomtek official website. ⚫ Ethernet ⚫ Chipset ⚫ Graphic ⚫ Audio ® ⚫ Intel ® ⚫ Intel Rapid Storage technology 【Note】: All specifications and images are subject to change without notice.

  • Page 14: Dimensions

    Series User’s Manual 1.3 Dimensions The following diagrams show dimensions and outlines of the eBOX630A. 1.3.1 System Dimensions Introduction...

  • Page 15: Wall-Mount Bracket Dimensions

    Series User’s Manual 1.3.2 Wall-mount Bracket Dimensions From the accessories box, users can get 4pcs of truss head M3*6L screws for fixing the wall mount kit. Note: When users install the wall mount kit, please turn the LAN ports side outlet towards the floor.
  • Page 16 Series User’s Manual Wall-mount Bracket Assembly Drawing From the accessories box, users can get 4pcs of truss head M3*6L screws for fixing the wall mount kit. Note : If users install the screws in drywall, use the hollow wall anchors to ensure that the unit does not pull away from the wall due to prolonged strain between the cable and the power connector.

  • Page 17: Din-Rail Bracket Dimensions

    Series User’s Manual 1.3.3 DIN-Rail Bracket Dimensions From the accessories box, users can get 4pcs of truss head M3*6L and 6pcs of M3*4L countersunk flat head screws for fixing the DIN-rail mount kit. DIN-Rail Bracket Assembly Drawing From the accessory box, users can get 6pcs of truss head M3*6L screws for fixing the wall mount kit.

  • Page 18: I/O Outlets

    Series User’s Manual 1.4 I/O Outlets The following figures show I/O outlets on the eBOX630A. Front View 2 x Antenna opening 1 x Remote power switch 2 x Swappable HDD drive bay 1 x AT/ATX quick switch 2 x Antenna opening 2 x USB 2.0...
  • Page 19 Series User’s Manual Rear View 1 x Grounding screw RS-232/422/485 (COM2) 1 x LAN (i226-LM) 2 x HDMI 1.4b 1 x Antenna opening 1 x DisplayPort++ RS-232 (COM4) 4 x USB 3.2 Gen 1 RS-232 (COM3) 2 x LAN (i226-IT)

  • Page 20: Packing List

    48 VDC Fanless embedded system with Intel® Celeron® 6305E, 2 eBOX630A-11U-CEL HDMI, 1 DisplayPort, 3x 2.5GbE LANs, 6 USB, 4 COM, and 9 to 48 VDC Please contact Axiomtek’s distributors immediately in case any abovementioned items are missing. Introduction...

  • Page 21: Section 2 Hardware Installation

    Series User’s Manual SECTION 2 HARDWARE INSTALLATION The eBOX630A is convenient for various hardware configurations, such as CPU, DRAM, HDD (Hard Disk Drive), SSD (Solid State Drive), PCI Express Mini card modules and optional MXM graphic module. Section 2 contains guidelines for hardware installation.
  • Page 22 Series User’s Manual Step 5 Place a thermal pad on the DRAM bracket and screw it on top of the DRAM. Step 6 Put the bottom cover back and fasten two screws back onto the system. Hardware Installation...

  • Page 23: Installation Of Mini Pcie Module (Full-Size)

    Series User’s Manual 2.2 Installation of Mini PCIe Module (Full-Size) Step 1 Turn off the system and unplug the power cord. Step 2 Turn the system upside down to locate screws at the bottom and loosen two screws as red marked.
  • Page 24 Series User’s Manual Step 5 Slot B is used as the wireless mini card slot, insert the Wi-Fi or LTE mini PCIe module into the slot and fasten the screw. Step 6 And then connect the cable to antenna opening.

  • Page 25: Installation Of Nvme Storage (M.2 Key M)

    Series User’s Manual 2.3 Installation of NVMe storage (M.2 Key M) Step 1 Turn off the system and unplug the power cord. Step 2 Turn the system upside down to locate screws at the bottom and loosen two screws as red marked.

  • Page 26: Installation Of 2.5" Sata Device

    Series User’s Manual 2.4 Installation of 2.5" SATA Device Step 1 Turn off the system and unplug the power cord. Step 2 Loosen two of the SATA drive tray’s screws and pull out the SATA HDD drive tray. Step 3 Turn the SATA drive tray upside down to install SSD/HDD and then fasten the four HDD screws to secure the SATA drive tray.

  • Page 27: Installation Of Sim Card

    Series User’s Manual 2.5 Installation of SIM Card Step 1 Turn off the system and unplug the power cord. Step 2 Loosen the screw of the SIM slot cover on chassis. Step 3 Make sure the SIM card direction is correct and insert the SIM card firmly.
  • Page 28 Series User’s Manual This page is intentionally left blank. Hardware Installation...

  • Page 29: Section 3 Jumper & Connector Settings

    3.1 Locations of Jumpers & Connectors PSB507 Top View 【Note】: It is strongly recommended that any unmentioned jumper settings should not be modified without instructions by Axiomtek FAEs. Any modifications without instructions might cause system failure. Jumper & Connector Settings...

  • Page 30: Summary Of Jumper Settings

    Series User’s Manual 3.2 Summary of Jumper Settings Proper jumper settings configure the eBOX630A to meet various application purposes. A table of all jumpers and their default settings is listed below. Jumpers Descriptions Settings Clear CMOS Short 1-2 CN23 Pin 1: DCD...

  • Page 31: Com1 Data/Power Selection (Jp3)

    Series User’s Manual 3.2.2 COM1 Data/Power Selection (JP3) This is a 2x3-pin (pitch=2.0mm) jumper. The COM1 port has +5V level power capability on DCD and +12V level on RI by setting jumper JP3. Functions Settings Power: Set CN21 pin 1 to +5V level...

  • Page 32: Connectors

    Series User’s Manual 3.3 Connectors Please refer to the below connector table to get information on pin assignments for individual connectors. External Connectors Sections DC-in Phoenix Power (CN22) 3.3.1 HDMI (CN17, CN18) 3.3.2 DisplayPort (CN21) 3.3.3 RS232/422/485 (CN23, CN24) 3.3.4...

  • Page 33: Dc-In Phoenix Power Connector (Cn22)

    Series User’s Manual 3.3.1 DC-in Phoenix Power Connector (CN22) The system supports 24V Phoenix DC-in connector for system power input. Pins Signals 3.3.2 HDMI Connector (CN17,CN18) The HDMI (High-Definition Multimedia Interface) is a compact digital interface which is capable of transmitting high-definition video and high-resolution audio over a single cable.

  • Page 34: Displayport++ (Cn21)

    Series User’s Manual 3.3.3 DisplayPort++ (CN21) The HDMI (High-Definition Multimedia Interface) is a compact digital interface which is capable of transmitting high-definition video and high-resolution audio over a single cable. 3.3.4 RS232/422/485 Serial Port Connector (CN23,CN24) The eBOX630A supports 2x RS-232/422/485 ports (COM1/COM2). Please refer to Chapter 4 for the details of BIOS settings.

  • Page 35: Ethernet + Usb 3.2 Connector (Cn15)

    Series User’s Manual 3.3.5 Ethernet + USB 3.2 Connector (CN15) CN15 is designed for 1x Ethernet port (Intel i226-LM) & two USB 3.2 ports. i226-LM LAN Port Pins LAN Signal Pins LAN Signal MDI0+ MDI2+ MDI0- MDI2- MDI1+ MDI3+...

  • Page 36: Usb 2.0 Connector (Usb1 , Usb2)

    Series User’s Manual 3.3.6 USB 2.0 Connector (USB1 , USB2) The Universal Serial Bus connectors are compliant with USB 2.0 (480Mbps) and ideal for installing USB peripherals such as a keyboard, mouse, scanner, etc... Pins Signal USB Port 0...

  • Page 37: Ethernet Port (Cn20)

    Series User’s Manual 3.3.8 Ethernet Port (CN20) One RJ-45 connector is designed by Intel i226-IT. Pins LAN Signal Pins LAN Signal MDI0+ MDI2+ MDI0- MDI2- MDI1+ MDI3+ MDI1- MDI3- Speed LED OFF: 10Mbps data rate OFF: 100Mbps data rate Amber: 1GMbps data rate Green: 2.5GMbps data rate...

  • Page 38: Atx Power On/Off (Sw3)

    Series User’s Manual 3.3.10 ATX Power on/off (SW3) The ATX power button is on the I/O side. It can allow users to control eBOX630A power on/off. Functions Descriptions Turn on/off system Keep system status 3.3.11 Reset Button (SW2) The Reset button can allow users to reset the eBOX630A system.

  • Page 39: Audio Connector (Cn3, Cn4)

    Series User’s Manual 3.3.14 Audio Connector (CN3, CN4) The Audio jacks ideal for Audio Mic-In and Audio Line-out. Pins Signals Line Out Microphone In 3.3.15 RS-232 Serial Port Connector (CN16, CN12) The eBOX630A supports 2x RS-232 ports (COM3/COM4). Please refer to Chapter 4 for the details of BIOS settings.

  • Page 40: Sata Connector (Sata 1 & 2)

    Series User’s Manual 3.3.16 SATA Connector (SATA 1 & 2) These Serial Advanced Technology Attachment (Serial ATA or SATA) connectors are used for high-speed SATA interfaces. They are computer bus interfaces for connecting to devices such as hard disk drives. This board has two SATA 3.0 ports with 6Gb/s performance.

  • Page 41: Full-Size Pci Express Mini Card Slot (Cn8)

    Series User’s Manual 3.3.19 Full-Size PCI Express Mini Card Slot (CN8) The eBOX630A supports one full-size PCI-Express Mini Card slots.CN8 is applying to either PCI-Express or USB 2.0 signal and complies with PCI-Express Mini Card Spec. V1.2. Pins Signals...

  • Page 42: 2280 Key M (Cn6)

    Series User’s Manual 3.3.20 M.2 2280 Key M (CN6) The M.2 2280 Key M for NVMe storage. Pins Signals Pins Signals Pins Signals Pins Signals +3.3V +3.3V PEX3_RX- PEX3_RX+ +3.3V LED_1# PEX3_TX- +3.3V PEX3_TX+ +3.3V PEX2_RX- +3.3V PEX2_RX+ PEX2_TX-...

  • Page 43: 2230 Key E (Cn7)

    Series User’s Manual 3.3.21 M.2 2230 Key E (CN7) The M.2 2230 Key E for Wi-Fi. +3.3V USB_D+ +3.3V USB_D- CONNECTOR Key E CONNECTOR CONNECTOR Key CONNECTOR CONNECTOR Key E Key E Key E CONNECTOR CONNECTOR Key CONNECTOR Key E...
  • Page 44 Series User’s Manual This page is intentionally left blank. Jumper & Connector Settings...

  • Page 45: Section 4 Bios Setup Utility

    Series User’s Manual SECTION 4 BIOS SETUP UTILITY This section provides users with detailed descriptions in terms of how to set up basic system configurations through the BIOS setup utility. 4.1 Starting To enter the setup screens, follow the steps below: Turn on the computer and press the <Del>...

  • Page 46: Main Menu

    Series User’s Manual 4.3 Main Menu The Main Menu screen is the first screen users see when entering the setup utility. Users can always return to the Main setup screen by selecting the Main tab. System Time/Date can be set up as described below.

  • Page 47: Advanced Menu

    Series User’s Manual 4.4 Advanced Menu The Advanced menu also allows users to set configuration of the CPU and other system devices. Users can select any items in the left frame of the screen to go to sub menus: ►...
  • Page 48 Series User’s Manual Trusted Computing If users install a security device, such as TPM, users will see the following information for the TPM device and status. BIOS Setup Utility...
  • Page 49 Series User’s Manual CPU Configuration This screen shows the CPU version and its detailed information. Hyper-Threading Use this item to enable or disable Hyper-Threading Technology, which makes a single physical processor perform multi-tasking functions as two logical ones. ®...
  • Page 50 Series User’s Manual Storage Configuration This screen allows users to select options for SATA Configuration and change the value of the selected option. SATA Controller Enable or disable the SATA Controller feature. The default is Enabled. Serial ATA Port 0-2 It shows the device installed in connector SATA1~2.
  • Page 51 Series User’s Manual AMT Configurations Users can use this screen to configure AMT parameters. Intel AMT Enable or disable Intel Active Management Technology BIOS Extension. ® The default is enabled. BIOS Setup Utility...
  • Page 52 Series User’s Manual F81966 Super IO Configuration Use this screen to select options for the F81966 Super IO Configurations and change the value of the selected option. A description of the selected item appears on the right side of the screen.
  • Page 53 Series User’s Manual Serial Port 1 Use this to set parameters of COM 1. COM Port type Use this item to set parameters related to serial ports COM 1 (RS232/422/485) BIOS Setup Utility...
  • Page 54 Series User’s Manual Serial Port 2 Use this to set parameters of COM 2. COM Port type Use this item to set parameters related to serial ports COM 2 (RS232/422/485) BIOS Setup Utility...
  • Page 55 Series User’s Manual Serial Port 3 Serial Port 4 BIOS Setup Utility...
  • Page 56 Series User’s Manual Hardware Monitor This screen monitors hardware health status. This screen displays the temperature of system and CPU as well as system voltages (VCORE, +5V_STBY, VBAT, +5V and +3.3V). BIOS Setup Utility...
  • Page 57 Series User’s Manual Serial Port Console Redirection This screen allows you to set serial port console redirection. Console Redirection Console Redirection Enable or Disable. Console Redirection Settings The settings specify how the host computer and the remote computer (which the user is using) will exchange data.
  • Page 58 Series User’s Manual USB Configurations Display all detected USB devices. BIOS Setup Utility...
  • Page 59 Series User’s Manual Device Configurations This item allows users to set the Digital I/O to Input or Output. Default is 4 IN & 4 OUT. BIOS Setup Utility...

  • Page 60: Chipset Menu

    Series User’s Manual 4.5 Chipset Menu The Chipset menu allows users to change the advanced chipset settings. Users can select any of the items in the left frame of the screen to go to the sub menus: ► System Agent (SA) Configurations ►...
  • Page 61 Series User’s Manual System Agent (SA) Configurations This screen allows users to configure System Agent (SA) parameters. For items marked with “”, please press <Enter> for more options. Memory Configuration Use this item to refer to the information related to system memory.
  • Page 62 Series User’s Manual Memory Configurations This screen shows the system memory information. BIOS Setup Utility...
  • Page 63 Series User’s Manual PCH-IO Configurations This screen allows users to set PCH parameters. BIOS Setup Utility...
  • Page 64 Series User’s Manual Security Menu Administrator Password This item indicates whether an administrator password has been set (installed or uninstalled). User Password This item indicates whether a user password has been set (installed or uninstalled). Secure Boot Secure Boot feature is Active if Secure Boot is Enabled, Platform Key (PK) is enrolled and the System is in User mode.
  • Page 65 Series User’s Manual Secure Boot Use this item to enable or disable support for Secure Boot. Secure Boot Mode Secure Boot mode options: Standard or Custom. In Custom mode, Secure Boot Policy variables can be configured by a physically present user without full authentication.
  • Page 66 Series User’s Manual Key Management Install factory default Secure Boot key the platform rest and while the System is in Setup mode. BIOS Setup Utility...

  • Page 67: Boot Menu

    Series User’s Manual 4.6 Boot Menu The Boot menu allows users to change boot options of the system. Setup Prompt Timeout Use this item to set up number of seconds to wait for setup activation key where 65535(0xFFFF) means indefinite waiting.

  • Page 68: Save & Exit Menu

    Series User’s Manual 4.7 Save & Exit Menu The Save & Exit menu allows users to load system configurations with optimal or fail-safe default values. Save Changes and Exit When users have completed the system configuration changes, select this option to leave Setup and return to Main Menu.
  • Page 69 Series User’s Manual Save Changes Having completed the system configuration changes, select this option to save changes. Select Save Changes from the Save & Exit menu and press <Enter>. Select Yes to save changes. Discard Changes Select this option to quit Setup without making any permanent changes to the system configurations.
  • Page 70 Series User’s Manual This page is intentionally left blank. BIOS Setup Utility...

  • Page 71: Appendix Awatchdog Timer

    Series User’s Manual APPENDIX A WATCHDOG TIMER About Watchdog Timer Software stability is major issue in most applications. Some embedded systems are not watched by human for 24 hours. It is usually too slow to wait for someone to reboot when a computer hangs.

  • Page 72: Sample Program

    Series User’s Manual Sample Program The following example enables configurations using a debug tool. Enable WDT  Enable configuration: O 2E 87; Un-lock super I/O O 2E 87  Select logic device: O 2E 07 O 2F 08 ...
