09) Switching on of the contact for the time t1 with the
button pressed and for the time t2 with the button released
Pressing the A button (rising edge) will switch on the relay for the time t
switch on the relay for the time t
for the time t will not occur. If the subsequent pressing will take place during the timing of time t
1
whole next cycle will be skipped.
.
PCS533 programmable time relay – User manual v. 1.0.1
Command: Return to
Select step: 1
Number of repetitions: 0
If the trailing edge occurs before the end of the t
2.
Command: Input A
Type: Wait for a rising edge
Time: 0 s
Command: Output
Type: Turn on
Time: 0 s
Command: Pause
Time: 1 s
Command: Output
Type: Turn off
Time: 0 s
Command: Input A – special function
Type: Low level
Action: Reset
Time: 0.1 s
Execution of the
transferred to step 1 - waiting for
the pressing of a button A. The
number of repetitions is set to 0
which means that this cycle can be
repeated indefinitely.
. Releasing the button (trailing edge) will
1
timing, then the switching on
1
The relay waits for the pressing of a
button A. The time is set to 0
seconds, so the relay will react
directly to pressing. Up to this point
the execution of the program is
stopped.
Set the relay in the on position.
Time 0 - the relay will remain on
until the next Output command will
change it.
Pause t suspends the execution of
1
the rest of the program for a preset
time (default - 1 s). After this time
the next step of the program is
executed.
Set the relay in the off position.
Time 0 - the relay will remain off
until the next Output command will
change it.
This step will be responsible for
breaking the cycle in case the
button is released before time t
elapses. If the low level at the
output A will sustain for 0.1 s the
program will be restarted and its
execution will start from the
beginning.
program is
, then the
1
1
