Bar with the function keys on the bottom of the screen:
o Save to file. This command allows you to save the current list of programs to a file. When you
press the button, a dialog box appears that allows you to enter a file name.
The file saved in this way will be available from the Load from file command that is located in the
main menu of the application.
PCS533 programmable time relay – User manual v. 1.0.1
Fig. 10) Program window
Fig. 11) Saving program to a file
Please note: The application does not verify whether a file with the entered name
already exists. If you will use the same name, the new configuration will
be overwritten in place of the previous one without displaying any
additional warning.
