PCU-530
Time relay,
universal
Do not dispose of this device in the trash along with other waste!
According to the Law on Waste, electro coming from households free of charge and can
give any amount to up to that end point of collecti on, as well as to store the occasion of
the purchase of new equipment (in accordance with the principle of old-for-new, regard-
less of brand). Electro thrown in the trash or abandoned in nature, pose a threat to the
environment and human health.
Purpose
The PCU-530 time relay is used for time control in industrial
and home automation systems (such as : ventilation, heating,
lighting, signaling, etc.)
Functions
OFF delay (A)
Until the relay is switched on, the contacts remain in position 5-4/
After the power supply voltage is applied (green LED [U] lit) the
contacts switch to the 5-6/8-9/11-12 position and the set time 't'
(red LED
lit) starts running. After the time 't' has elapsed the
contacts return to position 5-4/8-7/11-10. The relay can operate
again after the supply voltage is disconnected and then switched
on again.
F&F Filipowski L.P.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71
www.fif.com.pl; e-mail: biuro@fif.com.pl
- 1 -
