Rational iCombi Pro Original Installation Instructions page 57

2. Set the voltage at the switch in accordance with the power supply. In its
base position, the switch is in Position 2:
Position
1
2
3
1. Close the electrical compartment.
2. Connect the unit to mains power.
3. Switch the unit on.
4. Use the control panel to select the service level. Navigate to Basic Settings -
Other - Installation Voltage. Set the voltage.
5. Switch the unit off and on again. The changes will now be applied.
80.06.083_iCombiPro-iCombiClassic_IM_en-US
1
Voltage (V)
240
208/440
480
6 | Electrical connection
2 3
57 / 100
