3.2.1 Unit dimensions

Unit size XS GN
XS
XS
Unit size 6 half size to 10 full size GN
6 half size
6 full size
10 half
size
10 full size 1072
80.06.083_iCombiPro-iCombiClassic_IM_en-US
Width Width
(mm) x (inch)
655 25 3/4
Depth overall
dimension
(mm)
621
Width Width
(mm) x (inch)
850 33 1/2
1072 42 1/4
850 33 1/2
42 1/4
Depth Depth
(mm) y (inch)
555 21 7/8
Depth overall Overall height
dimension (mm)
(inch)
24 1/2 594
Depth Depth
(mm) y (inch)
775 30 1/2
975 38 3/8
775 30 1/2
975 38 3/8
3 | Product description
Height Height
(mm) z (inch)
567 22 3/8
Overall height
(inch)
23 1/2
Height Height
(mm) z (inch)
754 29 5/8
754 29 5/8
1014 39 7/8
1014 39 7/8
