Product description
3.1
Unit description
Unit size XS GN
The connections for the installation are located on the rear side of the unit:
6
1
Equipotential bonding (Earth
ground)
3
Electrical connection
5
Safety overflow for wastewater
connection
Unit size 6 half size to 10 full size GN
The connections for the installation are located on the rear side of the unit:
8
7
6
1
Network connection
3
Power supply
5
Optional connection
7
Safety overflow for wastewater
connection
80.06.083_iCombiPro-iCombiClassic_IM_en-US
5
4
3
2
2
Water connection
4
Drain connection
6
Network connection
2
Only for gas units: gas connection
For electric units only: electrical
connection
4
Water connection
6
Wastewater connection
8
Equipotential bonding (Earth
ground)
3 | Product description
1
1
2
3
4
5
13 / 100
