Minimum distance to the unit

5.1.1 Distance from walls

Minimum distance to all sides
Set up the unit taking into account the minimum distances to the wall. The dis-
tances depend on the unit size, as shown in the table below.
Unit size
x (mm)
x (inch)
y (mm)
y (inch)
z (mm)
z (inch)
Recommended distance to the left side of the unit
To ensure that there is sufficient space on the left side of the unit to carry out
service work in the installation area, place the unit on the left side at a recom-
mended minimum distance from the wall.
30 / 100
XS 6 half
size
10 50
1/2 2
10 0
1/2 0
10 50
1/2 2
6 full 10 half
size size
50 50
2 2
0 0
0 0
50 50
2 2
