Teldat S.A.
Note
The screws and anchors are not delivered with the router.
There are two slots on the underside of the device that can be used to fix it to the wall. You can see this in the follow-
ing figure:
To mount the router on a wall or another surface, follow these steps:
Procedure
Step 1. Align the two screws (3.5x30 mm) horizontally on a wall (or any other vertical surface) and install them 116.5
mm (4.56 inches) apart.
The screws should protrude 6 mm (0.25 inch) from the wall surface.
Warning
If you are installing the screws into drywall, use hollow-wall anchors (8 mm – 5/16 inch) to secure the
screws. If the screws are not properly anchored, the strain of the cables connected to the router's back
panel could pull the router from the wall.
Step 2. Hang the router on the screws.
3.3.3 19'' Rack installation
The RS300 device can be installed in a 19" rack.
Note
The rack mount kit, composed of strips and screws, is not delivered with the router by default and must
be acquired separately.
Rack installation
Fig. 11:
RS300 Series
3 Components and Power Supply
9
