INSTALLATION/REMOVAL
REMOVAL CHANNEL 3/4 ELECTROTHERAPY MODULE
Disconnect Mains Power
WARNING
Disconnect the system from the power source (outlet or remove
battery module if installed) before attempting any maintenance,
installation, removal, or replacement procedures to prevent electrical
shock and possible damage to system.
Disconnect the Mains Power Cord from
the power supply. Remove the Rear Access
Panel and disconnect the Mains Power
Cord from the Therapy System.
MAINS
POWER
CORD
REAR
ACCESS
PANEL
Remove Therapy System from Cart
Remove the Therapy System from the
Therapy System Cart, if equipped. Refer to
the Therapy System Cart User Manual for
proper instructions.
Place Therapy System face down on a clean
working surface protected with a soft, clean
fabric to prevent damage to the lens.
103
Intelect® Advanced Therapy System
NOTE:
It is not necessary to remove the
sEMG Module from the Channel 3/4
Electrotherapy Module, if installed.
Remove Lead Wires and Accessories
Remove the Front Access Cover and
disconnect the Lead Wires and Accessories
from the Therapy System and Channel 3/4
Electrotherapy Module.
REMOVE LEAD
WIRES AND
ACCESSORIES
NOTE:
Keep Lead Wires and accessories for later
re-installation to the Therapy System.
