INSTRUCTION MANUAL

Scope of delivery

Rotoclear S3 is supplied in a shock-protected, en-
vironmentally friendly packaging.
Upon receiving the product, please check that its
contents are complete and undamaged.
Only use the original packaging for return trans-
port and dismantle the rotor to protect the bear-
ings during transportation.
Please also see the section entitled "Trouble-
shooting"
The scope of delivery comprises different parts,
depending on the type of mounting and equip-
ment.
All packages contain
• Rotoclear S3 basic unit
(rotor and stator)
• Cylinder bolt M5 Tx10
• Operating manual DE / EN
All complete packages contain
• Protective hose (2 m)
• Hose fitting
• Air hose (8 m)
• Power cable (10 m)
• Electric-pneumatic adapter
• Elbow fitting
The adhesive-mounted version also
includes
• Adhesive-mounted flange with cover
• Two-component adhesive
• Cleaning cloth
• Dosing gun for
two-component adhesive
The screw-mounted version also includes
• Position template
(screw-mounted version)
• Screw-mounted flange
(6–16 mm clamping range)
The replacement kit for S and S2
additionally
contains
• Adapter flange
(6–16 mm clamping range)
• Flange for machinery glass
• Cylinder bolt M5 × 16
• Cylinder bolt M5 × 20
• Cylinder bolt M5 × 25
• Safety window 2 years
• Cable bushing M16
51
1 ×
10 ×
1 ×
1 ×
2 ×
1 ×
1 ×
1 ×
1 ×
1 ×
1 ×
1 ×
1 ×
1 ×
1 ×
1 ×
1 ×
1 ×
24 ×
12 ×
1 ×
1 ×
