Power Unit Assemblies

2
3
4
5
Item Description
1 Vent Plug
2 5/16-18x5/8 Hex Hd Screw
3 1/4-20x1-1/2 Socket Hd Screw
4 Flat Washer
5 Driver Block
6 Gearhead
7 Pipe Plug (magnetic)
8 Pinion Assembly
9 "S" Hook
10 Motor
-- Cord Assembly
-- Connector (Romex)
-- Connector (90 Degree)

Power Unit Assembly Part Numbers:

Part No. HP RPM
3259-84 1/3 HP 348 RPM
3259-85 1/2 HP 348 RPM
3259-98 1/2 HP 348 RPM
3259-100 1/2 HP 348 RPM
3259-128 1/2 HP 348 RPM
9
1
8
7
6
3259-8 3259-25
Part No. Part No.
3516 3516
4412-1 4412-1
5083-8 5083-8
1484 1484
4642 4642
3261-5 3261-5
30160 30160
5046 5046
4270 4270
4229 5703
4685 8299
1317 1317
- - - - - - - -
Phase Hz
Single Phase 60 Hz
Single Phase 60 Hz
Single Phase 50 Hz
Three Phase 50 Hz
Three Phase 60 Hz
Model H2™ Plus Feeding Systems
10
3259-84 3259-85 3259-98
Part No. Part No. Part No.
3516 3516 3516
4412-1 4412-1 4412-1
5083-8 5083-8 5083-8
1484 1484 1484
4642 4642 4642
3261-5 3261-5 3261-11
30160 30160 30160
5046 5046 5046
4270 4270 4270
4229 5703 5977
- - - - - - - - 28028
- - - - - - - - - - - -
- - - - - - - - 4228
Voltage Usages
230 Use with all Control Units except 1878 Control Units
230 Use with all Control Units except 1878 Control Units
230 Use with all Control Units
220/380 Use with all Control Units
230 Use with all Control Units
1660-21 1/2001
3259-100 3259-128
Part No. Part No.
3516 3516
4412-1 4412-1
5083-8 5083-8
1484 1418
4642 4642
3261-11 3261-5
30160 30160
5046 5046
4270 4270
28031 24624
- - - - - - - -
- - - - - - - -
- - - - - - - -
