3.12

Installing the conductivity detector

Accessories
930 Compact IC Flex ChS/Deg (2.930.1260)
1 Fasten the capillary labeled rinsing solution to the outlet of an inline
filter (6.2821.120) using a pressure screw (6.2744.070).
2 Use a pressure screw (6.2744.070) to fasten a piece of the PTFE
capillary (6.1803.030) to the inlet of the inline filter.
3 Use a pressure screw (6.2744.070) and an adapter (6.2744.080) to
fasten the other end of the PTFE capillary to Port 3 of the Dosino.
4 Connect the FEP tubing (6.1805.120) from the bottle with the rinsing
solution with the adapter (6.1808.280) to Port 4 of the Dosino.
The 930 Compact IC Flex provides enough space for one detector and
additional accessories in the detector chamber. The detector is available as
separate device and is supplied with a separate manual.
Placing the detector in the instrument
Follow the instructions in the chapter Inserting the detector in the manual
for the detector.
Connecting the detector to the eluent path
NOTE
The separation column is not inserted into the instrument until it is
being started up for the first time. Until then, the detector inlet capillary
has to be connected to the out capillary of the Metrohm Suppressor
Module (MSM) using a coupling (6.2744.040).
For this step, you need the following accessories:
3 Installation
￭￭￭￭￭￭￭￭
