5.11 Metrohm Suppressor Module (MSM)
5.11.2

Taking care of the suppressor housing

5.11.3

Servicing the Metrohm Suppressor Module (MSM)

5.11.3.1 Parts of the Metrohm Suppressor Module
(MSM)
1
Figure 21 Parts of the Metrohm Suppressor Module (MSM)
1 Union nut
3 Rotor
5 Slot in the housing
￭￭￭￭￭￭￭￭
74
CAUTION
The Metrohm Suppressor Module (MSM) must be regenerated (see
Chapter 5.11.3.2, page 75), cleaned (see Chapter 5.11.3.4, page 77)
or replaced (see Chapter 5.11.3.5, page 80) if the capacity of the Met-
rohm Suppressor Module (MSM) is reduced or if the back pressure is
high.
CAUTION
The transparent suppressor housing can become fogged.
The suppressor housing is made of PMMA (poly(methyl methacrylate)).
It can become scratched and foggy if cleaned improperly. This can make
viewing the rotor difficult or impossible.
Do not use any scouring agents for cleaning.
￭
Do not use any solvents for cleaning.
￭
2
3
2 Connecting piece
4 Housing
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
4
5
930 Compact IC Flex ChS/Deg (2.930.1260)
