2.3 Feed-throughs for capillaries and cables

7 Exhaust opening
Labeled Exhaust. For extracting the air from
the vacuum chamber.
9 Service connection socket
For Metrohm service only.
11 Drainage tubing connections
For connecting two drainage tubings that
guide the escaped fluid to the leak sensor
and from there to the waste container.
13 Type plate
15 Leak sensor connection socket
Labeled Leak Sensor. For connecting the
leak sensor connection cable.
17 MSB connection sockets
Labeled MSB 1 and MSB 2. For connecting
MSB devices.
19 PC connection socket
For connecting the instrument to the com-
puter with the USB cable (6.2151.020).
21 Power socket
Power socket for connecting the power
cable and power switch for switching the
instrument on and off.
2.3 Feed-throughs for capillaries and cables
￭￭￭￭￭￭￭￭
10
Multiple openings are available for leading capillaries into the instrument
and for leading capillaries and cables out of the instrument:
Openings on the door
￭
Openings on the back panel
￭
Ducts between the instrument and the base tray as well as between
￭
the instrument and the bottle holder (see Figure 5, page 13)
8 Auxiliary connection socket
For connecting an 891 Professional Analog
Out (2.891.0010).
10 Transport locking screws
For securing the high-pressure pump when
transporting the instrument.
12 Base tray
With leak sensor.
14 Serial number
16 Detector connection socket
Labeled Detector. For connecting Metrohm
detectors.
18 USB connection sockets
Labeled USB 1 and USB 2. For connecting
USB devices.
20 Vacuum connection
Plugged with a stopper.
930 Compact IC Flex ChS/Deg (2.930.1260)
￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
