3.12 Installing the conductivity detector
3.12
Installing the conductivity detector
■■■■■■■■
36
Inline filter (6.2821.120)
■
PTFE capillary (6.1803.030)
■
Adapter M6/UNF (6.2744.080)
■
FEP tubing M6 / 100 cm (6.1805.120)
■
Adapter Dosino Port 4, M6 inner (6.1808.280)
■
1 Fasten the capillary labeled rinsing solution to the outlet of an inline
filter (6.2821.120) using a pressure screw (6.2744.070).
2 Use a pressure screw (6.2744.070) to fasten a piece of the PTFE
capillary (6.1803.030) to the inlet of the inline filter.
3 Use a pressure screw (6.2744.070) and an adapter (6.2744.080) to
fasten the other end of the PTFE capillary to Port 3 of the Dosino.
4 Connect the FEP tubing (6.1805.120) from the bottle with the rinsing
solution with the adapter (6.1808.280) to Port 4 of the Dosino.
The 930 Compact IC Flex provides enough space for one detector and
additional accessories in the detector chamber. The detector is available as
separate device and is supplied with a separate manual.
Placing the detector in the instrument
Follow the instructions in the chapter Inserting the detector in the manual
for the detector.
■■■■■■■■■■■■■■■■■■■■■■
930 Compact IC Flex Oven/ChS (2.930.2200)
