Chapter 4 — Library Specifications
P S
OWER PECIFICATIONS
This section describes the power specifications for the library.

Input Power Requirements

The input power requirements for the library depend on the type and
number of drives installed in the library, as described in the following
table. Each branch circuit must be protected by a 15 amp circuit breaker.
a. Each branch circuit must be protected by a 15 amp circuit breaker.
b. If the male connector does not have a twist lock. An additional grounding wire from the chassis to earth
c. Requires a 220–240 VAC AC power cord with a twist-lock male connector.
d. When more than eight RXT drives are installed in the library, the library must be connected to a 200–

Power Cord Specifications

The power cords included with the library are considered part of the
library and cannot be used with any other equipment.
See
cords available from Spectra Logic.
38
Site Prep Guide
Note: The T200 library supports a maximum of eight drives and both
the T380 library and the T680 library support a maximum of
twelve drives each.
Number and Type of Drives
1 – 12 tape drives
(LTO, SDLT, SAIT)
1 – 8 RXT150 drives
d
1 – 12 RXT150 drives
ground is required.
See Power Cord Specifications
240 VAC power source.
Note: When using an 2N redundant power configuration, connect each
AC power cord to a separate branch circuit protected by a circuit
breaker rated for 15 amps.
Supply-end Connector Types on page 40
Electrical Rating
100–130 VAC, 50/60 Hz
200–240 VAC, 50/60 Hz
100–130 VAC, 50/60 Hz
200–240 VAC, 50/60 Hz
(below) for detailed information about power cord requirements.
Current Rating
(Maximum)
b
12 amps per cord
c
8 amps per cord
c
12 amps per cord
d
8 amps per cord
for the different types of
a
91010004
