Power Consumption and Cooling Requirements

The power and cooling requirements for the library depend on the number
and type of drives installed. The following table provides the nominal and
maximum power consumption specifications for the base library with no
QIPs or drives installed.
The following table provides the power and cooling requirements for
typical configurations of the library.
Drive Type
LTO Drives
(QIP-attached Fibre
Channel LTO-4)
SDLT Drives
SAIT Drives
RXT Drives
(RXT Gold media)
November 2008
Parameter Specification
Power
Nominal: 125 watts
Consumption
Maximum: 175 watts
Heat Load Nominal: 427 BTU/hour
Maximum: 598 BTU/hour
Mode Measurement
Standby Mode Power Consumption (Watts)
(Minimum)
Heat Dissipation (BTU/hour)
Read/Write/Seek Power Consumption (Watts)
Mode (Maximum)
Heat Dissipation (BTU/hour)
Standby Mode Power Consumption (Watts)
(Minimum)
Heat Dissipation (BTU/hour)
Read/Write/Seek Power Consumption (Watts)
Mode (Maximum)
Heat Dissipation (BTU/hour)
Standby Mode Power Consumption (Watts)
(Minimum)
Heat Dissipation (BTU/hour)
Read/Write/Seek Power Consumption (Watts)
Mode (Maximum)
Heat Dissipation (BTU/hour)
Standby Mode Power Consumption (Watts)
(Minimum)
Heat Dissipation (BTU/hour)
Read/Write/Seek Power Consumption (Watts)
Mode (Maximum)
Heat Dissipation (BTU/hour)
Number of Drives Installed
4
240
820
400
1366
310
1059
490
1673
320
1093
500
1708
410
1400
510
1742
Spectra T200, T380, and T680 Library
Power Specifications
8 12
305 370
1042 1264
550 700
1878 2391
495 680
1690 2322
805 1120
2749 3825
515 710
1759 2425
825 1150
2817 3927
695 980
2373 3347
845 1180
2886 4030
