Chapter 1 — Library Overview
Interior Components
Figure 2
Figure 2 Library interior components (T380 shown).
The optional BlueScale Vision camera is installed at the top of the library.
Figure 3 The BlueScale Vision camera and LEDs
18
Site Prep Guide
shows the interior components of the library.
Media chambers
(also behind fan
assembly)
Fan assembly
Media
chambers
DBA cover
Transporter with
bar code reader
LED (one on each
side of camera)
Ethernet cable
Camera lens
91010004
