Front Panel Components

Figure 1
Figure 1 Library front and side panel components (T380 shown).
November 2008
shows the library front and side panel components.
LCD touch screen
Power button
TeraPack Access
Port (TAP)
Front panel
Fans and air filter
(behind cover panel)
Note:
Most service procedures for the interior components require
access to the right-hand side of the library.
If the rack used for the T200 or T380 library does not provide
side access, the library must be removed from its rack in
order to remove the access panels.
The side panels on the T680 rack can be removed to expose
the access panels.
Alternatively, service can be performed by removing the
library's front panel and all the media packs stored in the
front chambers.
Spectra T200, T380, and T680 Library
Chassis Layout
Stylus
Access panels
Handles
