Rear Panel Components

Figure 4
Figure 4 Rear panel components (T380 2N redundant power supply option shown).
November 2008
shows the rear panel components of the library.
Flex bays (for DBAs
or chambers)
Drive Bay Assembly
(DBA)
Power supply
modules
Note: During normal operation, the following additional components
are present on the rear panel:
A DBA cover is installed over the drives (see
Figure 2 on page
Doors on the T680 rack enclose the back of the library.
Cord locks are installed to prevent the AC power cords from
being disconnected (see
A permanent grounding wire is connected to the chassis (see
Figure 5 on page
Any bays that do not contain components have covers
installed to maintain proper air circulation through the
library.
18).
Figure 5 on page
23).
Spectra T200, T380, and T680 Library
Chassis Layout
Tool storage
Chambers (3)
(behind cover)
Empty drive bay
(cover removed)
Drive
Empty controller bay
(cover removed)
QIP or bus
expansion module
Library Control
Module (LCM)
Main AC power cord
connector and switch
23).
