Installation Overview; Unpack And Set Up - Spectra Logic T-Series Spectra T200 Supplementary Manual

I
NSTALLATION
Before the field engineer arrives to install your library, read the Spectra
T200, T380, and T680 User Guide—available at
documents—to familiarize yourself with the library's features and
operation. During installation, the procedures described in the following
sections are used to set up and configure your library.
During installation, the engineer performs the procedures described in the
following sections.
The information in this section is for reference only. This information provides a
Important
high-level summary of the installation steps and is not intended for use as an
installation guide.

Unpack and Set Up

Refer to the Spectra T200, T380, and T680 User Guide at
www.spectralogic.com/documents
1. Unpack all components and verify that there was no shipping damage.
2. Install the library in a standard 19-inch rack at the requested location,
3. The library is installed at the bottom of the rack for stability.
The rack must be located on a level, hard-surfaced floor such as cement or tile. Do
Caution
not place the rack on a carpeted floor or anywhere else that poses risk for static
discharge that could damage your library and its drives.
If the library is loaded with media packs (RXT media packs or media in TeraPacks),
Spectra recommends that the library not be moved. If you must move the library,
contact SpectraGuard Technical Support for recommendations before proceeding.
4. Install the QIPs, drives, and power supply modules that were ordered
5. Install cord locks and attach the power cords and a permanent
November 2008
O
VERVIEW
Note:
The library will be installed by a certified Spectra Logic field
representative.
ensuring that it is located near an easily accessible AC power outlet and
away from potential sources of static discharge (for example, carpeted
flooring).
with the library.
grounding wire to the library. Power on the library.
The library comes with dual AC power inputs. If the library uses 2N
redundant power supply modules, each of these inputs is connected to
a separate circuit, which allows for failover in the event of a power
failure in one of the circuits. Refer to the user guide for the location of
the cable connectors, installation instructions for the cord locks and
grounding wire, and for power-on instructions.
www.spectralogic.com/
for additional information.
Spectra T200, T380, and T680 Library

Installation Overview

33
