Rack Installation

Important
Do not remove any of the libraries from their racks.
Spectra T200 or T380
The library MUST be installed in a rack. This section describes the rack-
mounting requirements for these two libraries.
The T200/T380 library must be installed in a standard 19-inch (48 cm) rack to
Warning
prevent tipping. The rack must be located on a level, hard-surfaced floor such as
cement or tile.
German: Die T200/T380 Library muss installiert sein, in einem Standard-Rack
48 cm Ablagerung zu verhindern. Das Rack muss sich auf eine ebene, harte
Oberfläche Stock wie Zement oder Fliese.
The rails provided with the library are designed for a standard 4-post 19-inch
Warning
(48 cm) rack.
German: Die Schienen, die mit der Bibliothek sind für ein Standard-4-post-19-Zoll
(48 cm) Rack.
Both libraries are designed to fit in a standard 19-inch, 4-post rack but may
be too deep for some enclosed racks. An additional 3 inches of depth at the
back of the rack may be required to allow for cable clearance. See
Accessibility on page 25
minimum recommended clearances around the library.
Check your rack's specifications to make sure it will accommodate the
weight and depth of the library. Using a 4-post rack that is at least 43 inches
(110 cm) deep is recommended. A rack that allows access to the library's
side panels simplifies maintenance and service procedures. For stability,
Spectra Logic recommends mounting the library at the bottom of the rack.
Make sure that the rack is assembled and placed near the AC power outlets
and network connections.
Spectra T680
The T680 ships from the factory in its own rack. Allow an additional 24
inches (61 cm) of clearance at both the front and back of the rack to open
the rack doors.
November 2008
Library Height
T200 35 inches (89 cm)
T380 49 inches (125 cm)
A 2-post rack will not support the weight of the library
A 2-post-Rack wird nicht das Gewicht der Bibliothek
Note: An enclosed 19-inch, four-post rack is available for purchase
from Spectra Logic at www.spectralogic.com/shop. The rack has
two doors and removable side panels to provide access to the
sides of the library.
Rack Space
20U
28U
and page 26 for the library dimensions and the
Spectra T200, T380, and T680 Library
Installation Preparation
.
.
31
