North American 100–130 VAC Power Cord The power cables included with
the library are standard, three conductor, 14-gauge AC power cords safe
for 100-volt to 130-volt use in the United States and Canada. The male
connector does not have a twist lock. An additional grounding wire from
the chassis to earth ground is required.
Risk of electrical shock. To prevent the possibility of electrical shock, install cord
Warning
locks on the AC power cords and a permanent grounding wire between the chassis
and earth ground.
German: Gefahr eines elektrischen Schlages. Um zu verhindern, dass die
Möglichkeit eines elektrischen Schlages, der Installation von Kabel-Sperren auf
den AC Netzkabel und eine ständige Erdung Draht zwischen den Chassis und
Masse.
Refer to the table in
Caution
maximum number of drives that can be installed when operating the library at
100–130 VAC.
North American and Korean 200–240 VAC Power Cord The criteria for a
200-volt to 240-volt AC power cord in North America and Korea are as
follows. Power cord must:
Cordage must be SJT type, three-conductor, 16 AWG minimum.
International 200–240 VAC Power Cord The criteria for an international
200-volt to 240-volt AC power cord are as follows. Power cord must:
Cord must be a flexible, HAR (harmonized) type H05VV-F, three
conductor, cord with minimum conductor size of 0.03 square inches (1.0
square millimeter).
November 2008
Input Power Requirements on page 38
Note:
To use the library outside of North America, the power cord
must meet the specifications for that country, as described in the
following sections. If the male connector does not have a twist
lock, an additional grounding wire from the chassis to earth
ground is required.
have a molded NEMA L6-20P male connector on one end
have a molded IEC 60320-C19 female connector to plug into the library
comply with local electrical code
have an attachment plug of the proper type, rating, and safety approval
for the intended country
have a molded IEC 60320-C19 female connector on one end to plug into
the library
to determine the
Spectra T200, T380, and T680 Library
Power Specifications
