Chapter 3 — Installation Preparation
Placement with Existing Equipment
It may be necessary to install the library next to previously installed
equipment in your data center. Servicing the library's interior components
is most easily accomplished from the right side (when viewed from the
front). For this reason, Spectra Logic recommends placing the library so
that its right side is accessible. See
the minimum recommended clearances around the library.
Special servicing arrangements can be made to suit your equipment
configuration. If you have any questions or concerns regarding the
placement of your library in your data center, contact Spectra Logic
Professional Services. See
Installed Library Weight
The following table shows the maximum weight of the installed library
when fully loaded with media, power supply modules, QIPs, and the
maximum number of tape drives.
This weight does not include the weight of the rack mounting hardware.
The actual weight varies, depending on the number of drives, QIPs, power
supplies, and TeraPack containers, as well as media, installed in the library.
After the installation is complete, Spectra Logic recommends that you do
not move the library. If you must move the library, contact Spectra Guard
Technical Support for recommendations.
Spectra T200 or T380—
The T200/T380 library must be installed in a standard 19-inch (48 cm) rack to
Warning
prevent tipping. The rack must be located on a level, hard-surfaced floor such as
cement or tile.
German: Die T200/T380 Library muss installiert sein, in einem Standard-Rack
48 cm Ablagerung zu verhindern. Das Rack muss sich auf eine ebene, harte
Oberfläche Stock wie Zement oder Fliese.
The T200/T380 library is very heavy. Always use four people, two on each side,
Warning
when lifting or moving the library.
German: Die T200/T380 Library ist sehr schwer. Benutzen Sie immer vier
Personen, zwei auf jeder Seite, beim Heben oder Fortbewegen der Library.
32
Site Prep Guide
Library
T200 428 pounds (194 kg)
T380 627 pounds (284 kg)
T680 1211 pounds (549 kg)
Accessibility on page 25
Contacting Spectra Logic on page
Weight
and page 26 for
6.
