Chapter 3 — Installation Preparation
Clearance
Before moving the library and components to where they will be installed,
make sure that you have access to necessary doorways, stairways,
hallways, and elevators, as well as adequate clearance to move through
them.
Tilting
Avoid tilting the library as it is moved to prevent internal components
moving out of their normal positions.
If you tilt the library, Spectra Logic is not responsible for any damage caused to the
Warning
library or its components, or for any damage caused to your site.
German: Wenn Sie neigen Sie die Bibliothek, Spectra Logic ist nicht verantwortlich
für Schäden, die auf die Bibliothek oder seiner Bestandteile oder für irgendwelche
Schäden, die auf Ihre site.
I
NSTALLATION
Your Spectra library will be installed for you by a certified Spectra Logic
field representative. Do not attempt to install the library yourself.
Review the requirements in
following sections to ensure that the site where the library will be installed
meets the necessary requirements before the Spectra Logic field engineer
arrives.
30
Site Prep Guide
Doorways (including thresholds) must be wider than 48 inches
(122 cm) and taller than:
T200/T380—90 inches (229 kg)
T680—93 inches (236 cm)
Stairwells must be wider than 48 inches (122 cm) and taller than:
T200/T380—90 inches (229 kg)
T680—93 inches (236 cm)
Stairway and hallway corners should be wider than 67 inches (170 cm).
Elevators and elevator doors should be wider than 48 inches (122 cm)
and taller than:
T200/T380—90 inches (229 kg)
T680—93 inches (236 cm
Elevators should be able to transport at least:
T200/T380—500 pounds (227 kg)
T680—1000 pounds (454 kg)
Note: It may be necessary to remove the top cover of the T680 to
ensure that it fits through a standard 80-inch door.
P
REPARATION
Chapter 2– Site Requirements, as well as the
