1. Turn the Key Switch (A) to the off position.
2. Press and hold the Detergent System switch (B).
3. While holding the switch, turn the Key Switch to the on position.
4. Continue to hold the switch until the detergent indicator is yellow.
5. Release the Detergent System switch. The bottom line of the display will now show the carpet icon, the AXP
enabled or disabled icon, the default detergent ratio and the offset value.
6. Press the Wand Switch (G) to toggle between the default setting for AXP being on or off.
7. Press the Scrub ON Switch (J) to toggle between the different ratio offsets.
• "0" indicates no offset.
• "-" indicates a -10% offset,
• "+" indicates a +10% offset in the amount of detergent pumped.
8. Press the AXP switch to change the default ratio when the AXP system does
not sense one selected on the detergent bottle. This ratio can be one of nine
settings from 1:32 to 1:300.
9. When the correct settings are selected press the Scrub OFF Switch (H) to save
them. The display will now show a key icon to indicate the procedure is done.
10. Turn the Key Switch to the off position. The new settings will be saved and will
remain in effect until they are changed again.

Factory Reset

It may be necessary in some circumstances to reset all of the machines parameters
back to the default factory settings. This can be accomplished by following this
procedure:
1. Turn the Key Switch (A) to the off position.
2. Press and hold the Wand Switch (G) , the Vacuum Switch (E) and the Scrub OFF Switch (H).
3. While holding these switches, turn the Key Switch to the on position.
4. Continue to hold the switches until the heavy scrub indicator turns yellow and the key icon is shown on the display.
5. Release the switches.
6. Turn the Key Switch to the off position.
7. Turn the Key Switch to the on position. The display will now show the AXP icon or an AXP icon with a cross through
it. The AXP icon represents the AXP system is enabled, and the AXP icon with a cross through it represents it is
disabled. Press and release the AXP switch to toggle between the two.
8. When the correct setting is selected press the scrub system off switch to save it.
9. The display will now show a key icon to indicate the procedure is done. Turn the main power key switch to the off
position.
10. The new setting will be saved and will remain in effect until it is changed again.
