If the scrub system is activated in the maintenance or restoration extraction mode, pressing this switch will cause the
following to occur:
• The solution system will toggle between disabled and enabled. The solution flow will only turn on when the throttle is
moved from the neutral position in the forward direction. The solution flow will turn off if the throttle returns to neutral
or is moved to reverse.
• The solution indicator will be green if the solution is on. If the solution is off, this indicator will be off. The indicator
will be yellow if the solution has been enabled but the throttle is in neutral. If there is a solution system fault, the
indicator will flash yellow.
Display Panel (D)
Refer to the Control Panel Indicators - AquaPLUS subsection for a description of the display functions.
Vacuum Switch (E)
This switch toggles the vacuum system on or off.
• The vacuum will only turn on when the throttle is moved from the neutral position. It will remain on for 10 seconds
after the throttle returns to neutral.
• The vacuum indicator will be green if the vacuum is on. It will flash green if the vacuum is in the 10-second delayed-
off condition. If the vacuum is off, this indicator will be off. The indicator will be yellow if the vacuum has been
enabled but the throttle is in neutral. If there is a vacuum system fault, the indicator will flash yellow.
Speed Control Fault Indicator (F)
If a speed control fault occurs (error code 3), the Speed Control Fault Indicator in the Wand Switch (G) will flash the
fault code produced by the Curtis speed control. Refer to the Electrical/Curtis Controller Diagnostics section for
details.
Wand Switch (G)
This switch is used when an external scrub wand is used. Pressing this switch will turn the vacuum on continuously
without regard to the throttle position. It will also enable the solution pump. If the scrub system was on, it will be turned
off. This includes turning off the scrub brushes, raising the scrub deck and turning the solution flow to the scrub deck
off. The indicator in the Wand Switch will be green when the wand function is on. Otherwise it will be off.
Scrub OFF Switch (H)
Pressing this switch when the scrub system is active will cause the following to occur:
• The scrub brushes will turn off and the scrub deck will rise to the up position.
• The solution flow will be stopped.
• The vacuum will shut off after a 10-second delay
• The travel speed limit will return to the transport speed setting.
• The display will indicate the nozzles are turned off and the deck is in the raised position.
• The scrub off indicator will be green if the scrub system is off and ready to be activated. The indicator will be off if
the scrub system has been activated. If the scrub system has been turned off and the scrub deck is not up yet, the
indicator will be red. If there is a fault in the scrub system this indicator will flash red.
