Drive Wheel Removal
Warning!
Warning!
1. Remove the squeegee (if so equipped) and place wood blocking in front and rear of the opposite drive wheel that
you are removing to prevent the machine from rolling.
2. Using a scissors jack, raise the machine until the wheel is off the ground. See Figure 25 for jack placement.
3. Remove the four Locknuts (E) and the Drive Wheel (F).
4. Reinstall the Drive Wheel by following the above steps in reverse order.
Figure 25
66 - Form No. 56043116 - Adphibian™/AX 651 Multi EDS/AquaPLUS™
Disconnect the battery pack before servicing machine.
Never work under machine without safety stands or blocking to support the machine.
